ProCap 3.2 Sets New Standard in Flow Measurement Visualization and User Experience

Posted on

The latest version of the industry-leading ProCap aerodynamics 3D flow measurement and visualisation system, ProCap 3.2, has officially launched, bringing a suite of powerful new features aimed at enhancing data visualisation, streamlining workflow, and delivering a highly intuitive user interface. With features designed specifically for professionals and compact users alike, ProCap 3.2 represents a major leap forward in precision and usability.

ProCap 3.2 Professional now features surface flow maps. Introducing surface projections, enables real-time mapping of measured data such as velocity and static pressure directly onto model surfaces. This new feature provides deeper insight into flow characteristics and significantly enhances analytical capabilities.

Developed directly in conjunction with user feedback, the new interface is fast, fluid, and fully interactive. Users can now preview changes instantly and make reversible adjustments for a more efficient and intuitive setup experience. Available for both Compact and Professional versions.

Enhanced data analysis tools include adjustable transparency for model geometries and isosurfaces, as well as improved line rendering for streamlines. These enhancements allow users to better interpret complex flow fields and streamline configurations.

New Workflow Features

  • Simplified Model Positioning: Easily position models using relative coordinates.
  • Setup Cloning: Clone previous setups as templates for new measurements—saving time and reducing errors.
  • Advanced Probe & Data Handling

ProCap 3.2 improves data handling with:

  • Active COM-port listings
  • User-defined thresholds on incoming data
  • Enhanced options for appending data to stored files

ProCap 3.2 is now available for download. For more information or to upgrade your current version, please contact EvolutionMeasurement.com
